Price:
From £91.00 Ex. VAT
Price:
From £91.00 Ex. VAT
Small advanced tracker with multi-source connectivity
Provides vehicle telemetry such as the vehicles battery voltage, speed, location and more
Bluetooth connectivity for external devices and Low Energy sensors
Features |
||
|---|---|---|
| Installation | Requires installation | |
| Portal | Real time tracking supported by our own tracking platform | |
| Immobiliser | Remotely immobilise your vehicle in the event of a theft | |
| Crash detection | Using the inbuilt accelerometer, track your vehicle and be alerted in the event of a crash | |
| Eco-driving | Monitor how your efficiency with Eco-driving analysis, by measuring acceleration, braking and cornering | |
| Speeding detection | Keep your fleet safe by monitoring driver behaviour | |
| Jamming detection | Disrupt thieves using GNSS jamming to steal from your vehicles (Jamming detection supported with SLM320-E and SLM320-LA modules) | |
| GNSS Fuel Counter | Measure fuel consumption and the rate of fuel consumption | |
| Excessive idling detection | Monitor your vehicles idling times and save money | |
| Unplug detection | Get an alert if the tracker is removed, which stops tampering with the device and ensuring your protection | |
| Towing detection | Get alerted if your vehicle is being towed | |
| Geofencing | Get geofencing alerts using user-defined areas | |
| Sensors | Accelerometer | |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep | |
| Configuration and firmware update | FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth®) | |
| SMS | Configuration, Events, DOUT control, Debug | |
| GPRS commands | Configuration, DOUT control, Debug | |
| Time Synchronization | GNSS, NITZ, NTP | |
| Fuel monitoring | LLS (Analog), Digital LLS (RS232, RS485), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle | |
| Ignition detection | Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle) | |
| RS232 Modes | Log Mode, NMEA, LLS, LCD, RFID HID/MF7, Garmin FMI, TCP ASCII/Binary, Satellite Backup (Iridium Edge) | |
| RS485 Modes | Log Mode, NMEA, LLS, TCP ASCII/Binary | |
Module |
||
| Name | FMC125-MBIB0: MeiG SLM320-E with Teltonika TM2500 FMC125-MCIB0: MeiG SLM320-LA with Teltonika TM2500 | |
| Technology | LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH® LE | |
GNSS |
||
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS | |
| Receiver | 33 tracking channel 99 acquisition channel | |
| Tracking sensitivity | -165 dBM | |
| Position Accuracy | < 2.5 m CEP | |
| Hot start | < 1 s | |
| Warm start | < 25 s | |
| Cold start | < 35 s | |
| Velocity Accuracy | < 0.1 m/s (within +/- 15% error) | |
Cellular |
||
| Technology | LTE Cat 1, GSM | |
| 2G bands | FMC125-MBIB0: GSM: B2/B3/B5/B8 FMC125-MCIB0: GSM: B2/B3/B5/B8 | |
| 4G bands | FMC125-MBIB0: LTE FDD: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41 FMC125-MCIB0: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40 | |
| Data transfer | LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL) LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL) GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL) | |
| Data support | SMS (text/data) | |
Power |
||
| Input voltage range | 10 – 30 V DC with overvoltage protection | |
| Internal Back-up battery | 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) | |
| Internal fuse | 3A, 125V | |
| Power consumption | At 12V < 4 mA (Ultra Deep Sleep) At 12V < 6 mA (Deep Sleep) At 12V < 12 mA (Online Deep Sleep) At 12V < 19 mA (GPS Sleep) At 12V < 36 mA (nominal with no load) At 12V < 1A Max. (with full Load / Peak) | |
Bluetooth technology |
||
| Specification | 4.0 + LE | |
| Supported peripherals | Temperature and Humidity sensor, OBDII dongle, Inateck Barcode Scanner, Universal Bluetooth® LE sensors support | |
Interface |
||
| Digital Inputs | 2 | |
| Digital Outputs | 1 | |
| Analog Inputs | 1 | |
| CAN Adapter Inputs | 1 | |
| 1-Wire | 1 | |
| RS232 | 1 | |
| RS485 | 1 | |
| GNSS antenna | Internal High Gain | |
| Cellular antenna | Internal High Gain | |
| USB | 2.0 Micro-USB | |
| LED indication | 2 status LED lights | |
| SIM | 2x SIM Card (Dual-SIM) | |
| Memory | 128MB internal flash memory | |
Physical specification |
||
| Weight | 62 g | |
| Dimensions | 65 x 56.6 x 20.6 mm (L x W x H) | |
Operating environment |
||
| Operating temperature (without battery) | -20 °C to +85 °C | |
| Storage temperature (without battery) | -20 °C to +85 °C | |
| Operating humidity | 5% to 95% non-condensing | |
| Ingress Protection Rating | IP41 | |
| Battery charge temperature | 0 °C to +45 °C | |
| Battery discharge temperature | -20 °C to +60 °C | |
| Operating temperature (with battery) | -20 °C to +40 °C | |
| Storage temperature (with battery) | -20 °C to +40 °C | |
| Battery storage temperature | -20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months | |
Certification & approvals |
||
| Regulatory | CE/RED, E-Mark, EAC, RoHS, REACH, CITC, RCM, JATE, TELEC, IMDA, SIRIM QAS, SDPPI POSTEL, KC, ICASA, NBTC |
Small advanced tracker with multi-source connectivity
Provides vehicle telemetry such as the vehicles battery voltage, speed, location and more
Bluetooth connectivity for external devices and Low Energy sensors
