FMB003 – Advanced plug and play

FMB003 advanced plug and play fleet tracking device
FMB003 advanced plug and play fleet tracking device (side)
FMB003 advanced plug and play fleet tracking device (front)

Price:

From £105.00 Ex. VAT

Advanced plug and play

  • Bluetooth connectivity
  • Small compact design for hard to reach plug in points
  • Easy plug-and-play installation
  • Built-in accelerometer for crash detection and monitoring driver behaviour
  • Built-in backup battery
  • Real time tracking with our tracking portal
  • CAN data reading for your specific needs
  • OBDII fault code diagnostics
  • Jamming detection
  • Overvoltage protection



What is a service package?

You may also like...

FMB003

Plug and play device with OEM parameters reading capability dedicated to OBD applications of next generation!

Our smallest GNSS OBDII based tracking device

Crash detection according to accelerometer data

Bluetooth connectivity for external devices and Low Energy sensors

FMB003 advanced plug and play fleet tracking device

Supported vehicles and data list

ECU Icon

Read standard OBDII data  from vehicle ECU

OBD OEM parameters (PIDs) – Real odometer and fuel level


Service Package

To ensure your experience is the very best, we manage all the complexities of mobile device configuration, management and connectivity to the Location Services Portal (LSP).
 This includes:
  • All-inclusive European multi-network roaming mobile data package with no hidden costs. Other geographic zones are available upon request.
  • Service support (9am to 5pm Mon – Fri) with best effort for out of hours, weekends, and bank holidays.
  • Secure high availability Location Services Portal (LSP) with 24/7 365 access, automated backups, disaster recovery, maintenance, upgrades, bug fixes, feature enhancements and continued security monitoring & patching.
  • Automated event notifications via SMS, Email, Webhook and or Push.
    Secure API integration options.
  • Continual device improvements (new features, security, and performance enhancements) via firmware over the air (FOTA).
  • 2-year rolling history, playback, and reporting.

Product Specifications

Features
Installation Easy, simple, plug-and-play installation that takes seconds, just plug the tracker into the OBD port and you are good to go!
Battery Contains an internal built-in backup battery in case the tracker is removed from the OBD port
Portal Real time tracking supported by our own tracking platform
CAN data Measure all sorts of CAN data such as fuel consumption or coolant temperature
Fault code diagnostics Know when your vehicle needs repair with fault code diagnostics
Crash detection Using the inbuilt accelerometer, track your vehicle and be alerted in the event of a crash
Eco-driving Monitor how your efficiency with Eco-driving analysis, by measuring acceleration, braking and cornering
Speeding detection Keep your fleet safe by monitoring driver behaviour
Jamming detection Disrupt thieves using GNSS jamming to steal from your vehicles
GNSS Fuel Counter Measure fuel consumption and the rate of fuel consumption
Excessive idling Monitor your vehicles idling times and save money
Unplug detection Get an alert if the tracker is removed from its OBD port, which stops tampering with the device and ensuring your protection
Towing detection Get alerted if your vehicle is being towed
Geofencing Get geofencing alerts using user-defined areas
Sensors Accelerometer
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update FOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth®)
SMS Configuration, Events, Debug
GPRS commands Configuration, Debug
Time Synchronization GNSS, NITZ, NTP
Fuel monitoring OBD II
Ignition detection Accelerometer, External Power Voltage, Engine RPM

Module
Name Teltonika TM2500
Technology GSM/GPRS/GNSS/BLUETOOTH

GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
Receiver 33 tracking channel
99 acquisition channel
Tracking sensitivity -165 dBM
Position Accuracy < 2.5 m CEP
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Velocity Accuracy < 0.1 m/s (within +/- 15% error)

Cellular
Technology GSM
2G bands Quad-band 850 / 900 / 1800 / 1900 MHz
Data transfer GPRS Multi-Slot Class 12 (up to 240 kbps)
Data support SMS (text/data)

Power
Input voltage range 10–30 V DC with overvoltage and reverse polarity protection
Internal Back-up battery į 45 mAh Li-Ion battery (0.167 Wh)
Power consumption At 12V < 5 mA (Ultra Deep Sleep)
At 12V < 7 mA (Deep Sleep)
At 12V < 7 mA (Online Sleep)
At 12V < 8 mA (GPS Sleep)
At 12V < 28 mA (nominal)

Bluetooth technology
Specification 4.0 + LE
Supported peripherals Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support

OBD interface
Data reading Up to 32 vehicle onboard parameters, supported OBD protocols:
ISO 9141-2 (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (5 baud init, 10.4 kbaud)
ISO 14230-4 KWP (fast init, 10.4 kbaud)
ISO 15765-4 CAN (11 bit ID, 250 kbaud)
ISO 15765-4 CAN (11 bit ID, 500 kbaud)
ISO 15765-4 CAN (29 bit ID, 250 kbaud)
ISO 15765-4 CAN (29 bit ID, 500 kbaud)
Data K-Line, CAN bus data

Interface
Connection OBDII Socket
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM Micro-SIM
Memory 128MB internal flash memory

Physical specification
Weight 30 g
Dimensions 52.6 x 29.1 x 26 mm (L x W x H)

Operating environment
Operating temperature (without battery) -40 °C to +85 °C
Storage temperature (without battery) -40 °C to +85 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Battery charge temperature 0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage temperature -20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months

Certification & approvals
Regulatory CE/RED, UKCA, E-Mark, EAC, RoHS, REACH, SIRIM QAS, Anatel, SDPPI POSTEL
